Contrôleur de moteur de moyeu arrière/avant BAFANG G062 G0900 48 V 750 W


Prix:
Prix réduit$59.99 USD

Description

Ce contrôleur 48 V, 750 W est conçu pour les moteurs moyeux BAFANG RM G062.750.DC et RM G0900.750.DC, compatibles avec les configurations à traction avant et arrière. Doté du protocole UART 5.9 de BAFANG et d'une limite de courant de 25 A, il garantit des performances fiables.

Fonctions de la prise :

  • Connecteur moteur 11 broches (femelle rouge)
  • Connecteur SM de phare à 2 broches (femelle jaune)
  • Connecteur de capteur PAS à 3 broches (femelle jaune)
  • Câble 1T4 8 broches (femelle noire) :
    • Support de levier de frein
    • Support d'affichage pour vélo électrique
    • Support d'accélérateur au pouce
  • Connecteur de batterie Anderson

Spécifications techniques :

  • Protocole : BAFANG UART 5.9
  • Tension : 48 V
  • Puissance : 750 W
  • Limite de courant : 25 A
  • Protection basse tension : 39 ± 1 V
  • Poids : 0,9 lb"

Customer Reviews

Based on 1 review
0%
(0)
0%
(0)
100%
(1)
0%
(0)
0%
(0)
D
Dennis Conner
No instructions

The part quality was new. No schematic nor wiring diagram was included. Connecting was self-intuitive; however, two wiring ends both had yellow(orange) sockets and there are two plugs with the same color. There are two many variations of Bafang controllers where Google couldn't help. Otherwise, all is installed and in great working order. Powallon is an exceptional and reliable vender. If there were instructions, I'd give 4-1/2 stars.
